Heat Shrink Thin Wall Sleeves

Heat Shrink Thin Wall Sleeves

5.00 INR/Piece

Product Details:

X

Price And Quantity

  • 5.00 INR/Piece
  • 1 Piece

Trade Information

  • 1000 Piece Per Day
  • 1-15 Days

Product Description

Highly flexible, irradiation cross linked tubing used for insulating, jacketing and bundling of wire  harnesses and components. Made from flame retardant polyolefin, it offers a excellent balance of electrical, mechanical, thermal, chemical and physical properties. Operates up to 135°C.

Features:

1. Halogen free, Flame retardant and self-extinguishing
2. For Electrical Insulation up to 600 volts
3. Resistance to chemical, copper corrosion and fungus
4. Standard Colors: Black, White, Yellow, Red, Blue, Green, Yellow/Green and Clear.



Product Details


Properties

Value

Standard

Physical

Tensile Strength

8 N/mm² (MPA)(Min.)

ASTM D 412-06a

Ultimate Elongation

150% (Min.)

ASTM D 412-06a

Water Absorption

0.5 % (max.)

ASTM D570

Thermal

Heat Shock (130oC for 30 Mins.)

No Cracking or flowing

ESI 09-11

Shrink Temperature

90°C

IEC 216

Continuous Temperature limit

-40°C to + 110°C

IEC 216

Electrical

Dielectric Strength

600V - 12kV

ASTM D149

Volume Resistivity

1X1015 Ohm.cm

ASTM D257

Flammability

Flammability

Pass

UL-94 (V-0)
